These 9-bit transceivers are designed for asynchronous communication between data buses. The control-function implementation allows for maximum flexibility in timing.
These devices allow data transmission from the A bus to the B bus or from the B bus to the A bus, depending upon the logic levels at the output-enable (
and
) inputs.
The outputs are in the high-impedance state during power-up and power-down conditions. The outputs remain in the high-impedance state while the device is powered down.
The SN54BCT29863B is characterized for operation over the full military temperature range of -55°C to 125°C. The SN74BCT29863B is characterized for operation from 0°C to 70°C.
| Supply voltage (min) (V) | 4.5 |
| Supply voltage (max) (V) | 5.5 |
| Number of channels | 9 |
| IOL (max) (mA) | 48 |
| IOH (max) (mA) | -24 |
| Input type | TTL |
| Output type | TTL |
| Features | Partial power down (Ioff), Power up 3-state, Very high speed (tpd 5-10ns) |
| Technology family | BCT |
| Rating | Catalog |
| Operating temperature range (°C) | 0 to 70 |
| SOIC (DW) | 24 | 159.65 mm² 15.5 x 10.3 |
