The UC1710 family of FET drivers is made with a high-speed Schottky process to interface between low-level control functions and very high-power switching devices-particularly power MOSFETx92s. These devices accept low-current digital inputs to activate a high-current, totem pole output which can source or sink a minimum of 6A.
Supply voltages for both VIN and VC can independently range from 4.7V to 18V. These devices also feature under-voltage lockout with hysteresis.
The UC1710 is packaged in an 8-pin hermetically sealed dual in-line package for x9655°C to +125°C operation. The UC2710 and UC3710 are specified for a temperature range of x9640°C to +85°C and 0°C to +70°C respectively and are available in either an 8-pin plastic dual in-line or a 5-pin, TO-220 package. Surface mount devices are also available.
| Number of channels | 1 |
| Power switch | IGBT, MOSFET |
| Peak output current (A) | 6 |
| Input VCC (min) (V) | 4.7 |
| Input VCC (max) (V) | 18 |
| Features | Thermal shutdown |
| Operating temperature range (°C) | 0 to 70 |
| Rise time (ns) | 25 |
| Fall time (ns) | 20 |
| Propagation delay time (µs) | 0.035 |
| Input threshold | CMOS |
| Channel input logic | Inverting, Non-Inverting |
| Input negative voltage (V) | 0 |
| Rating | Catalog |
| Undervoltage lockout (typ) (V) | 4 |
| Driver configuration | Complementary |
| PDIP (P) | 8 | 92.5083 mm² 9.81 x 9.43 |
| SOIC (DW) | 16 | 106.09 mm² 10.3 x 10.3 |
| TO-220 (KC) | 5 | 45.212 mm² 10.16 x 4.45 |
