The TLC393 consists of dual independent micropower voltage comparators designed to operate from a single supply. It is functionally similar to the LM393 but uses one-twentieth the power for similar response times. The open-drain MOS output stage interfaces to a variety of loads and supplies. For a similar device with a push-pull output configuration see the TLC3702 data sheet.
Texas Instruments LinCMOS process offers superior analog performance to standard CMOS processes. Along with the standard CMOS advantages of low power without sacrificing speed, high input impedance, and low bias currents, the LinCMOS™ process offers extremely stable input offset voltages, even with differential input stresses of several volts. This characteristic makes it possible to build reliable CMOS comparators.
The TLC393Q is characterized for operation over the full automotive temperature range of TA = −40°C to 125°C
| Number of channels | 2 |
| Output type | Open-collector, Open-drain |
| Propagation delay time (µs) | 1 |
| Vs (max) (V) | 16 |
| Vs (min) (V) | 4 |
| Vos (offset voltage at 25°C) (max) (mV) | 5 |
| Iq per channel (typ) (mA) | 0.011 |
| Input bias current (±) (max) (nA) | 0.03 |
| Rail-to-rail | In to V- |
| Rating | Automotive |
| Operating temperature range (°C) | -40 to 125 |
| VICR (max) (V) | 15 |
| VICR (min) (V) | 0 |
| SOIC (D) | 8 | 29.4 mm² 4.9 x 6 |
