The REF4132 device is a low temperature drift
(12 ppm/°C), low-power, high-precision CMOS voltage reference, featuring ±0.05% initial accuracy, low operating current with power consumption less than 100µA. This device also offers very low output noise of 15 µVp-p/V, which enables its ability to maintain high signal integrity with high-resolution data converters in noise critical systems. Packaged in the same SOT-23-5 package, REF4132 offers enhanced specifications and pin-to-pin replacement for LM4128 and LM4132.
Stability and system reliability are further improved by the low output-voltage hysteresis of the device and low long-term output voltage drift. Furthermore, the small size and low operating current of the devices (100 µA) can benefit portable and battery-powered applications.
REF4132 is specified for the wide temperature range of −40°C to +125°C.
| VO (V) | 2.5, 3, 3.3, 4.096, 5 |
| Initial accuracy (max) (%) | 0.05 |
| Temp coeff (max) (ppm/°C) | 12, 30 |
| Vin (min) (V) | 3 |
| Vin (max) (V) | 5.5 |
| Iq (typ) (mA) | 0.075 |
| Rating | Catalog |
| Features | Enable pin |
| LFN 0.1 to 10 Hz (typ) (µVPP) | 15 |
| Iout/Iz (max) (mA) | 10 |
| Operating temperature range (°C) | -40 to 125 |
| Shutdown current (ISD) (typ) (µA) | 2.5 |
| SOT-23 (DBV) | 5 | 8.12 mm² 2.9 x 2.8 |
