The LM9076Q is a ±3%, 150 mA logic controlled voltage regulator. The regulator features an active low delayed reset output flag which can be used to reset a microprocessor system at turn-ON and in the event that the regulator output voltage falls below a minimum value. An external capacitor programs a delay time interval before the reset output pin can return high.
Designed for automotive and industrial applications, the LM9076Q contains a variety of protection features such as thermal shutdown, input transient protection and a wide operating temperature range. The LM9076Q uses an PNP pass transistor which allows low drop-out voltage operation.
All trademarks are the property of their respective owners.
| Output options | Fixed Output |
| Iout (max) (A) | 0.15 |
| Vin (max) (V) | 40 |
| Vin (min) (V) | 3.65 |
| Vout (max) (V) | 5 |
| Vout (min) (V) | 3.3 |
| Fixed output options (V) | 3.3, 5 |
| Iq (typ) (mA) | 4.5 |
| Thermal resistance θJA (°C/W) | 156 |
| Rating | Automotive |
| Load capacitance (min) (µF) | 10 |
| Regulated outputs (#) | 1 |
| Accuracy (%) | 3 |
| PSRR at 100 KHz (dB) | 37 |
| Dropout voltage (Vdo) (typ) (mV) | 250 |
| Operating temperature range (°C) | -40 to 125 |
| SOIC (D) | 8 | 29.4 mm² 4.9 x 6 |
