TPS92010

正在供货

产品详情

The TPS92010 is a PWM controller with advanced energy features to provide high efficiency driving for LED lighting applications.

The TPS92010 incorporates frequency fold back and low power mode operation to reduce the operation frequency at light load and no load operations.

The TPS92010 is offered in the 8-pin SOIC (D) package. Operating junction temperature range is –40°C to 105°C.

LED Lighting Current Driver Controller with Energy Saving Features
Quasi-Resonant Mode Operation for Reduced EMI and Low Switching Losses (Low Voltage Switching)
Low Standby Current for Deep Dimming Efficiency Power Consumption
Low Startup Current: 25 µA Maximum
Programmable Line and Load Overvoltage Protection
- Provides Open LED Protection
Internal Overtemperature Protection
Current Limit Protection
- Cycle-by-Cycle Power Limit
- Primary-Side Overcurrent Hiccup Restart Mode
1-A Sink TrueDrive, –0.75-A Source Gate Drive Output
Programmable Soft-Start
APPLICATIONS
- Residential LED Lighting Drivers for A19 E12/E26/27, GU10, MR16, PAR30/38 Integral Lamps
- Drivers for Wall Sconces, Pathway Lighting and Overhead Lighting
- Drivers for Wall Washing, Architectural and Display Lighting

Topology	Flyback
Control mode	Current
Switching frequency (max) (kHz)	130
UVLO thresholds on/off (V)	10.3/6.3
Vin (max) (V)	21
Features	Overtemperature protection, Overvoltage protection, Programmable soft start
Rating	Catalog
Operating temperature range (°C)	-40 to 105
Duty cycle (max) (%)	99

SOIC (D)

29.4 mm² 4.9 x 6
