The TL4050-Q1 family of shunt voltage references are versatile easy-to-use references suitable for a wide array of applications. The two-terminal fixed-output device requires no external capacitors for operation and is stable with all capacitive loads. Additionally, the reference offers low dynamic impedance, low noise, and low temperature coefficient to ensure a stable output voltage over a wide range of operating currents and temperatures.
The TL4050-Q1 is available in three initial tolerances, ranging from 0.1% (maximum) for the A grade to 0.5% (maximum) for the C grade. Thus, a great deal of flexibility is available to designers in choosing the best cost-to-performance ratio for their applications. Packaged in the space-saving SOT-23-3 and SC-70 packages and requiring a minimum current of 45 µA (typical), the TL4050-Q1 also is ideal for portable applications.
The TL4050x-Q1 characterization is for operation over an ambient temperature range of –40°C to 125°C.
| VO (V) | 2.5 |
| Initial accuracy (max) (%) | 0.2 |
| VO adj (min) (V) | 2.5 |
| VO adj (max) (V) | 2.5 |
| Iz for regulation (min) (µA) | 41 |
| Reference voltage (V) | Fixed |
| Rating | Automotive |
| Temp coeff (max) (ppm/°C) | 50 |
| Operating temperature range (°C) | -40 to 125 |
| Iout/Iz (max) (mA) | 20 |
| SOT-23 (DBZ) | 3 | 6.9204 mm² 2.92 x 2.37 |
| SOT-SC70 (DCK) | 5 | 4.2 mm² 2 x 2.1 |
