• Single Supply Voltage: 3.3 V
• Low Power Consumption
• Sequences and Monitors up to Eight Voltage Rails
• Rail Voltages Sampled Every 50 µs With 3.2-mV Resolution
• Four Configurable Digital Outputs for Power-On Reset and Other Functions
• Configurable Rail-Enable Output Polarity
• Flexible Rail Sequencing: Timeline (ms), Parent Rail Regulation Window, Parent Rail Achieving Defined Threshold
• Under- and Overvoltage Thresholds: Settable Per-Rail
• Regulation Expiration Time: Settable Per-Rail
• Flexible Rail Shutdown: Parent Rail Shutdown Can Shut Down Child Rails, Independent Rail Configuration
• Per-Rail Alarm Conditions, With Timestamp: Under- and Overvoltage Glitch, Sustained Under- and/or Overvoltage, Rail Did Not Start
• I²C Interface for Configuration and Monitoring
• Microsoft™ Windows™ GUI for Configuration and Monitoring
• APPLICATIONS
  • Telecommunications Switches
  • Servers
  • Networking Equipment
  • Test Equipment
  • Any System Requiring Sequencing of Multiple Voltage Rails
