The LM26001B is a switching regulator designed for the high efficiency requirements of applications with stand-by modes. The device features a low-current sleep mode to maintain efficiency under light-load conditions and current-mode control for accurate regulation over a wide input voltage range. Quiescent current is reduced to 10 µA typically in shutdown mode and less than 40 µA in sleep mode. Forced PWM mode is also available to disable sleep mode.
The LM26001B can deliver up to 1.5A of continuous load current with a fixed current limit, through the internal N-channel switch. The part has a wide input voltage range of 4.0V to 18V and can operate with input voltages as low as 3V during line transients.
Operating frequency is adjustable from 150 kHz to 500 kHz with a single resistor and can be synchronized to an external clock.
Other features include Power good, adjustable soft-start, enable pin, input under-voltage protection, and an internal bootstrap diode for reduced component count.
All trademarks are the property of their respective owners.
| Vin (min) (V) | 3 |
| Vin (max) (V) | 18 |
| Vout (min) (V) | 1.25 |
| Vout (max) (V) | 16 |
| Iout (max) (A) | 1.5 |
| Iq (typ) (mA) | 0.038 |
| Switching frequency (min) (kHz) | 150 |
| Switching frequency (max) (kHz) | 500 |
| Features | Enable, Light Load Efficiency, Power good, Pre-Bias Start-Up |
| Operating temperature range (°C) | -40 to 125 |
| Rating | Catalog |
| Regulated outputs (#) | 1 |
| Control mode | current mode |
| Duty cycle (max) (%) | 98 |
| Type | Converter |
| HTSSOP (PWP) | 16 | 32 mm² 5 x 6.4 |
