• Controlled Baseline
  • One Assembly/Test Site, One Fabrication Site
• Extended Temperature Performance of -55°C to 125°C
• Enhanced Diminishing Manufacturing Sources (DMS) Support
• Enhanced Product-Change Notification
• Qualification Pedigree⁽¹⁾
• 30 m, 12 A Peak MOSFET Switches for High Efficiency at 6 A Continuous Output Source or Sink Current
• Adjustable Output Voltage Down to 0.9 V With 1% Accuracy
• Wide PWM Frequency: Fixed 350 kHz, 550 kHz or Adjustable 280 kHz to 700 kHz
• Synchronizable to 700 kHz
• Load Protected by Peak Current Limit and Thermal Shutdown
• Integrated Solution Reduces Board Area and Component Count
• APPLICATIONS
  • Low-Voltage, High-Density Distributed Power Systems
  • Point-of-Load Regulation for High-Performance DSPs, FPGAs, ASICs, and Microprocessors
  • Broadband, Networking, and Optical Communications Infrastructure
  • Portable Computing/Notebook PCs

⁽¹⁾ Component qualification in accordance with JEDEC and industry standards to ensure reliable operation over an extended temperature range. This includes, but is not limited to, Highly Accelerated Stress Test (HAST) or biased 85/85, temperature cycle, autoclave or unbiased HAST, electromigration, bond intermetallic life, and mold compound life. Such qualification testing should not be viewed as justifying use of this component beyond specified performance and environmental limits.

SWIFT, PowerPAD are trademarks of Texas Instruments.
