The OPA2544 is a dual high-voltage/high-current operational amplifier suitable for driving a wide variety of high power loads. It provides 2A output current and power supply voltage range extends to ±35V.
The OPA2544 integrates two high performance FET op amps with high power output stages on a single monolithic chip. Internal current limit and thermal shutdown protect the amplifier and load from damage.
The OPA2544 is available in a hermetic 8-pin metal TO-3, and 11-lead plastic packages. Models are available in -40°C to +85°C, and -55°C to +125°C temperature ranges.
| Number of channels | 2 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V) | 20 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V) | 70 |
| Iout (typ) (A) | 4 |
| GBW (typ) (MHz) | 1.4 |
| Slew rate (typ) (V/µs) | 8 |
| Vos (offset voltage at 25°C) (max) (mV) | 5 |
| Offset drift (typ) (V/°C) | 0.00001 |
| Iq per channel (typ) (mA) | 12 |
| Rating | Catalog |
| Operating temperature range (°C) | -40 to 105 |
| Input bias current (max) (pA) | 100 |
| CMRR (typ) (dB) | 106 |
| Rail-to-rail | No |
| Architecture | FET |
| TO-220 (KV) | 11 | 187.5874 mm² 20.02 x 9.37 |
