The LT1013x devices are dual precision operational amplifiers, featuring high gain, low supply current, low noise, and low-offset-voltage temperature coefficient.
The LT1013x devices can be operated from a single 5-V power supply; the common-mode input voltage range includes ground, and the output can also swing to within a few millivolts of ground. Crossover distortion is eliminated. The LT1013x can be operated with both dual ± 15-V and single 5-V supplies.
The LT1013C and LT1013D are characterized for operation from 0°C to 70°C. The LT1013DI is characterized for operation from –40°C to 105°C. The LT1013M, LT1013AM, and LT1013DM are characterized for operation over the full military temperature range of –55°C to 125°C.
| Number of channels | 2 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V) | 44 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V) | 4 |
| Vos (offset voltage at 25°C) (max) (mV) | 0.3 |
| GBW (typ) (MHz) | 0.7 |
| Slew rate (typ) (V/µs) | 0.4 |
| Rail-to-rail | In to V- |
| Offset drift (typ) (µV/°C) | 0.4 |
| Iq per channel (typ) (mA) | 0.35 |
| Vn at 1 kHz (typ) (nV√Hz) | 22 |
| CMRR (typ) (dB) | 114 |
| Rating | Catalog |
| Operating temperature range (°C) | 0 to 70 |
| Input bias current (max) (pA) | 30000 |
| Iout (typ) (A) | 0.025 |
| Architecture | Bipolar |
| Input common mode headroom (to negative supply) (typ) (V) | 0 |
| Input common mode headroom (to positive supply) (typ) (V) | -1.5 |
| Output swing headroom (to negative supply) (typ) (V) | 1.5 |
| Output swing headroom (to positive supply) (typ) (V) | -1 |
| PDIP (P) | 8 | 92.5083 mm² 9.81 x 9.43 |
| SOIC (D) | 8 | 29.4 mm² 4.9 x 6 |
