The CDC208 contains dual clock-driver circuits that fanout one input signal to four outputs with minimum skew for clock distribution (see Figure 2). The device also offers two output-enable (OE1 and OE2) inputs for each circuit that can force the outputs to be disabled to a high-impedance state or to a high- or low-logic level independent of the signal on the respective A input.
Skew parameters are specified for a reduced temperature and voltage range common to many applications.
The CDC208 is characterized for operation from -40°C to 85°C.
EPIC is a trademark of Texas Instruments Incorporated.
| Function | Single-ended |
| Output frequency (max) (MHz) | 60 |
| Number of outputs | 8 |
| Output supply voltage (V) | 5 |
| Core supply voltage (V) | 5 |
| Output skew (ps) | 1000 |
| Features | Dual 1 |
| Operating temperature range (°C) | -40 to 85 |
| Rating | Catalog |
| Output type | CMOS |
| Input type | TTL |
| SOIC (DW) | 20 | 131.84 mm² 12.8 x 10.3 |
| SOP (NS) | 20 | 98.28 mm² 12.6 x 7.8 |
