• 2.7-V to 5.5-V Analog Supply, Low Power:
  • 15.5 mW (1 MHz, +VA = 3 V, +VBD = 1.8 V)
• 1-MHz Sampling Rate 3 V ≤ +VA ≤ 5.5 V, 900-kHz Sampling Rate 2.7 V ≤ +VA ≤ 3 V
• Excellent DC Performance:
  ±1.0 LSB Typ, ±1.75 LSB Max INL
  ±0.5 LSB Typ, ±1 LSB Max DNL
  16-Bit NMC Over Temperature
  ±0.5 mV Max Offset Error at 3 V
  ±1 mV Max Offset Error at 5 V
• Excellent AC Performance at f_I = 10 kHz with 93 dB SNR, 105 dB SFDR, -102 dB THD
• Built-In Conversion Clock (CCLK)
• 1.65 V to 5.5 V I/O Supply:
  SPI/DSP Compatible Serial
  SCLK up to 50 MHz
• Comprehensive Power-Down Modes:
  Deep Power-Down
  Nap Power-Down
  Auto Nap Power-Down
• Unipolar Input Range: 0 V to V_REF
• Software Reset
• Global CONVST (Independent of CS)
• Programmable Status/Polarity EOC/INT
• 16-Pin 4 × 4 QFN and 16-Pin TSSOP Packages
• Multi-Chip Daisy Chain Mode
• Programmable TAG Bit Output
• Auto/Manual Channel Select Mode (ADS8330)
• APPLICATIONS
  • Communications
  • Transducer Interface
  • Medical Instruments
  • Magnetometers
  • Industrial Process Control
  • Data Acquisition Systems
  • Automatic Test Equipment
