Featuring over 4 million micromirrors, the DLP9000XUV digital micromirror device (DMD) enables high resolution and high performance spatial light modulation of UV wavelengths from 355 nm to 420 nm. The DLP9000XUV is designed with a special UV optimized window to support numerous applications in the industrial and medical markets. Reliable operation of the DLP9000XUV chipset requires the DMD be driven by the DLPC910 Controller. The DLP9000XUV chipset’s architecture enables continuous data streaming for very high speed lithographic applications. The 4.1 megapixel resolution of the DMD enables large 3D print build sizes and results in fine detail for Digital Lithography.
| Illumination wavelength (min) (nm) | 355 |
| Illumination wavelength (max) (nm) | 420 |
| Micromirror array size | 2560 x 1600 |
| Chipset family | DLP9000XUV, DLPC910, DLPR910 |
| Pattern rate, binary (max) (Hz) | 14989 |
| Pixel data rate (max) (Gbps) | 61.1 |
| Micromirror pitch (mm) | 0.0076 |
| Component type | DMD |
| Rating | Catalog |
| Display resolution (max) | 2560 x 1600 (WQXGA) |
| Pattern rate, 8-bit (max) (Hz) | 1873 |
| Micromirror array orientation | Orthogonal |
| Micromirror driver support | Integrated |
| Thermal dissipation (°C/W) | 0.5 |
| Operating temperature range (°C) | 20 to 30 |
| DLP-TYPEA.9 (FLS) | 355 | 1777.4656 mm² 42.16 x 42.16 |
