SN74AUC1G08

正在供货

单通道、2 输入、0.8V 至 2.7V 超高速 (2.4ns) 与门

立即搜索现货

产品详情|
产品购买|

产品详情

说明
特性
参数
封装 | 引脚 | 尺寸

This single 2-input positive-AND gate is operational at 0.8-V to 2.7-V V_CC, but is designed specifically for 1.65-V to 1.95-V V_CC operation.

The SN74AUC1G08 device performs the Boolean function in positive logic.

NanoFree™ package technology is a major breakthrough in IC packaging concepts, using the die as the package.

This device is fully specified for partial-power-down applications using I_off. The I_off circuitry disables the outputs, preventing damaging current backflow through the device when it is powered down.

Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II
ESD Protection Exceeds JESD 22
- 2000-V Human-Body Model (A114-A)
- 200-V Machine Model (A115-A)
- 1000-V Charged-Device Model (C101)
Available in the Texas Instruments NanoFree™ Package
Optimized for 1.8-V Operation and Is 3.6-V I/O Tolerant to Support Mixed-Mode Signal Operation
I_off Supports Partial-Power-Down Mode and Back Drive Protection
Sub-1-V Operable
Max t_pd of 2.4 ns at 1.8 V
Low Power Consumption, 10-µA Max I_CC
±8-mA Output Drive at 1.8 V

Technology family	AUC
Supply voltage (min) (V)	0.8
Supply voltage (max) (V)	2.7
Number of channels	1
Inputs per channel	2
IOL (max) (mA)	9
IOH (max) (mA)	-9
Input type	Standard CMOS
Output type	Push-Pull
Features	Over-voltage tolerant inputs, Partial power down (Ioff), Ultra high speed (tpd <5ns)
Data rate (max) (Mbps)	250
Rating	Catalog
Operating temperature range (°C)	-40 to 85

DSBGA (YZP)	5	2.1875 mm² 1.75 x 1.25
SOT-23 (DBV)	5	8.12 mm² 2.9 x 2.8
SOT-5X3 (DRL)	5	2.56 mm² 1.6 x 1.6
SOT-SC70 (DCK)	5	4.2 mm² 2 x 2.1
