The SM73308 is a single low noise precision operational amplifier intended for use in a wide range of applications. Other important characteristics include: an extended operating temperature range of −40°C to 125°C, the tiny SC70-5 package, and low input bias current.
The extended temperature range of −40°C to 125°C allows the SM73308 to accommodate a broad range of applications. The SM73308 expands TI’s Silicon Dust amplifier portfolio offering enhancements in size, speed, and power savings. The SM73308 is ensured to operate over the voltage range of 2.7V to 5.0V and has rail-to-rail output.
The SM73308 is designed for precision, low noise, low voltage, and miniature systems. This amplifier provides rail-to-rail output swing into heavy loads. The maximum input offset is 850 μV at room temperature and the input common mode voltage range includes ground.
The SM73308 is offered in the tiny SC70-5 package.
(Unless Otherwise Noted, Typical Values at VS = 2.7V)
All trademarks are the property of their respective owners.
| Number of channels | 1 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V) | 5.5 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V) | 2.7 |
| Vos (offset voltage at 25°C) (max) (mV) | 0.85 |
| GBW (typ) (MHz) | 3.5 |
| Features | Small Size |
| Slew rate (typ) (V/µs) | 1.4 |
| Rail-to-rail | In to V-, Out |
| Offset drift (typ) (µV/°C) | 0.35 |
| Iq per channel (typ) (mA) | 0.6 |
| Vn at 1 kHz (typ) (nV√Hz) | 7.5 |
| CMRR (typ) (dB) | 90 |
| Rating | Catalog |
| Operating temperature range (°C) | -40 to 125 |
| Input bias current (max) (pA) | 100 |
| Iout (typ) (A) | 0.066 |
| Architecture | CMOS |
| Input common mode headroom (to negative supply) (typ) (V) | 0 |
| Input common mode headroom (to positive supply) (typ) (V) | -0.9 |
| Output swing headroom (to negative supply) (typ) (V) | 0.112 |
| Output swing headroom (to positive supply) (typ) (V) | -0.1 |
| THD + N at 1 kHz (typ) (%) | 0.007 |
| SOT-SC70 (DCK) | 5 | 4.2 mm² 2 x 2.1 |
