The ’HC4060 devices consist of an oscillator section and 14 ripple-carry binary counter stages. The oscillator configuration allows design of either RC- or crystal-oscillator circuits. A high-to-low transition on the clock (CLKI) input increments the counter. A high level at the clear (CLR) input disables the oscillator (CLKO goes high and CLKO goes low) and resets the counter to zero (all Q outputs low).
| Function | Counter |
| Bits (#) | 14 |
| Technology family | HC |
| Supply voltage (min) (V) | 2 |
| Supply voltage (max) (V) | 6 |
| Input type | Standard CMOS |
| Output type | Push-Pull |
| Features | Balanced outputs, High speed (tpd 10-50ns), Positive input clamp diode |
| Operating temperature range (°C) | -40 to 85 |
| Rating | Catalog |
| PDIP (N) | 16 | 181.42 mm² 19.3 x 9.4 |
| SOIC (D) | 16 | 59.4 mm² 9.9 x 6 |
| SOP (NS) | 16 | 79.56 mm² 10.2 x 7.8 |
| SSOP (DB) | 16 | 48.36 mm² 6.2 x 7.8 |
| TSSOP (PW) | 16 | 32 mm² 5 x 6.4 |
