SN74LVCH16652A

正在供货

产品详情

This 16-bit bus transceiver and register is designed for 1.65-V to 3.6-V V_CC operation.

Member of the Texas Instruments Widebus™
Family
Operates From 1.65 V to 3.6 V
Inputs Accept Voltages to 5.5 V
Max t^pd of 6.3 ns at 3.3 V
Typical V_OLP (Output Ground Bounce)
< 0.8 V at V_CC = 3.3 V, T_A = 25°C
Typical V_OHV (Output V_OH Undershoot)
> 2 V at V_CC = 3.3 V, T_A = 25°C
Supports Mixed-Mode Signal Operation on All Ports
(5-V Input/Output Voltage With 3.3-V V_CC)
I_off Supports Partial-Power-Down Mode Operation
Bus Hold on Data Inputs Eliminates the Need for
External Pull-up or Pull-down Resistors
Latch-Up Performance Exceeds 250 mA Per
JESD 17
ESD Protection Exceeds JESD 22
- 2000-V Human-Body Model
- 200-V Machine Model
- 1500-V Charged-Device Model

Supply voltage (min) (V)	1.65
Supply voltage (max) (V)	3.6
Number of channels	16
IOL (max) (mA)	24
IOH (max) (mA)	-24
Input type	TTL/CMOS
Output type	LVTTL
Features	Balanced outputs
Technology family	LVC
Rating	Catalog
Operating temperature range (°C)	-40 to 125
