This device contains four independent 2-input positive-AND buffers/drivers. It performs the Boolean functions Y = A x95 B or
in positive logic.
The SN74AS1008A is characterized for operation from 0°C to 70°C.
| Technology family | AS |
| Supply voltage (min) (V) | 4.5 |
| Supply voltage (max) (V) | 5.5 |
| Number of channels | 4 |
| Inputs per channel | 2 |
| IOL (max) (mA) | 20 |
| IOH (max) (mA) | -2 |
| Input type | Bipolar |
| Output type | Push-Pull |
| Features | Very high speed (tpd 5-10ns) |
| Data rate (max) (Mbps) | 125 |
| Rating | Catalog |
| Operating temperature range (°C) | 0 to 70 |
| PDIP (N) | 14 | 181.42 mm² 19.3 x 9.4 |
| SOIC (D) | 14 | 51.9 mm² 8.65 x 6 |
