特性

• Reduces Design Complexity, Manufacturing Risks, and Time-to-Market
• Synchronous Step-Down DC-DC Converter With Integrated FETs
• Integrated Inductor
• Integrated Compensation Components
• Saves Board Space in Space-Constrained Applications
• Complete Integrated Step-Down Power Supply in a Single Package
• Small Profile 6.5mm x 10mm x 2.92mm SiP Package
• Simplified PCB Design with Minimal External BOM Components
• Offers Flexibility for Power-Design Optimization
• Wide Input Voltage Range from 4.5V to 76V
• Output-Voltage Adjustable Range from 0.8V to 5V
• Adjustable Frequency with External Synchronization (180kHz to 537kHz)
• Soft-Start Programmable
• Optional Programmable EN/UVLO
• Operates Reliably in Adverse Industrial Environments
• Integrated Thermal Fault Protection
• Robust Overcurrent Protection
• Active-Low RESET Output Voltage Monitoring
• High Industrial -40°C to +125°C Ambient Operating Temperature Range/-40°C to +150°C Junction Temperature Range
• Complies with CISPR22(EN55022) Class B Conducted and Radiated Emissions

产品详情和应用

应用

• 基站负载点稳压器
• 配电稳压器
• FPGA和DSP负载点稳压器
• HVAC与楼宇控制
• 工业电源
