推荐用于新设计
特性
- HDMI v1.4b/v2.0a Input Interface
- 3Gbps or 6Gbps Forward-Link Rates
- 187.5Mbps Reverse-Link Rate
- Full-Duplex Capability Over a Single Wire
- Ideal for High-Definition Video Applications
- Up to 215MHz PCLK per Link
- Up to 430MHz PCLK in Dual-Link Mode
- Uses Low-Cost 50Ω Coax or 100Ω STP Cables
- Forward and Reverse I2S or 7.1 TDM Audio
- Video Pattern Generator Provides Fast Link Validation
- Line-Fault Monitor Detects Serial I/O Shorted Together, to Ground, to Battery or Open
- ASIL-Relevant Functional Safety Features
- ASIL B Compliant
- 16-Bit CRC Protection of Control-Channel Data (I2C, UART, SPI, GPIO, Audio)
- Retransmission on Error of all Control-Channel Data and Audio Data Upon Error Detection
- Optional 32-Bit Video-Line CRC
- Selectable Interrupts for Fault Detection
- Video Watermark Generation
- Performance Tools Ensure High Link Margin
- Continuous Adaptive Equalization on GMSL Links
- Built-In Forward- and Reverse-Channel PRBS Generator for BER Testing of Serial I/O Links
- Eye-Opening Monitor for Link Diagnosis
- Concurrent Control Channel for Device Configuration and Communication with Remote Peripherals
- Primary and Pass-Through I2C/UART, SPI, and Tunneled or Register-Programmable GPIO
- Settable Priority Levels
- Eight Hardware Programmable Device Addresses
- Up to 20 Programmable GPIO
- Sleep Mode with Register State Retention
- Operation Specified Over the -40°C to +105°C Automotive Temperature Range
- AEC-Q100 Qualified
- Compact 8mm x 8mm TQFN with an Exposed Pad
产品详情和应用
The MAX96751 serializer converts HDMI® to single or dual GMSL™ serial protocol. It also sends and receives side-channel and peripheral control data, enabling full-duplex, single-wire, transmission of video and bidirectional data. Each GMSL2 link operates at a fixed rate of 3Gbps or 6Gbps in the forward direction and 187.5Mbps in the reverse direction.
The MAX96751 supports RGB888 video at up to 215MHz PCLK per GMSL2 link.
For designs supporting two displays, see the New Designs Supporting Two Displays section of Detailed Descriptions for more information.
The GMSL2 concurrent control channel operates in I2C or UART mode. Two additional pass-through I2C or UART channels and a pass-through SPI channel are provided for peripheral control. The bidirectional audio channel supports I2S stereo and up to 8 channels in Time-Division Multiplexing (TDM) mode.
Data can be transmitted over low-cost 50Ω coax or 100Ω STP cables that meet the GMSL2 Channel Specification. Contact the factory to receive the GMSL2 Channel Specification document.
APPLICATIONS
- Navigation and Touch-Panel Displays
- Digital Instrument Clusters and Heads-Up Displays
- Rear-Seat and Passenger Infotainment Displays
- Consumer HDMI Port Applications
