特性

• ±1 LSB INL
• 1µA Shutdown Current
• "Glitch Free" Output Voltage at Power-Up
• Single-Supply Operation
  • +5V (MAX5174)
  • +3V (MAX5176)
• Full-Scale Output Range
  • +2.048V (MAX5176, V_REF = +1.25V)
  • +4.096V (MAX5174, V_REF = +2.5V )
• Rail-to-Rail Output Amplifier
• Adjustable Output Offset
• Low THD (-80dB) in Multiplying Operation
• SPI/QSPI/MICROWIRE-Compatible 3-Wire Serial Interface
• Programmable Shutdown Mode and Power-Up Reset
• Buffered Output Capable of Driving 5kΩ || 100pF Loads
• User-Programmable Digital Output Pin Allows Serial Control of External Components
• 14-Bit Upgrades Available (MAX5170/MAX5172)

产品详情和应用

应用

• µP控制系统
• 自动测试设备(ATE)
• 数字增益与失调控制
• 工业过程控制
• 运动控制
• 远端工业控制
