ADI亚德诺 ADH514S 产品介绍
2026-03-09
0次
特性
- Dual Output:
- Fo = 11.17 GHz – 12.02 GHz
- Fo/2 = 5.58 GHz – 6.01 GHz
- Pout: + 7 dBm Typ.
- Phase Noise: -110 dBc/Hz @ 100 kHz Typ.
- No External Resonator Needed
- Screened in accordance with ADI Standard Space Products Program’s Enhanced Class Q model.
产品详情和应用
The ADH514S is a GaAs, InGaP, Heterojunction Bipolar Transistor (HBT), MMIC, VCO. The ADH514S integrates resonators, negative resistance devices, varactor diodes and feature half frequency and divide-by-4 outputs. The VCO’s phase noise performance is excellent over temperature, shock, and process due to the oscillator’s monolithic structure. Power output is +7 dBm typical from a +3 V supply voltage. The prescaler function can be disabled to conserve current if not required. The voltage-controlled oscillator requires no external matching components.
Applications
- Point-to-Point/Multi-Point Radios
- Industrial Controls
- Satellite Communications (SATCOM)
- Military & Space
