ADI亚德诺 ADL8201 产品介绍
2026-03-09
0次
特性
- Wideband frequency range: DC to 30GHz
- Insertion loss
- 0.3dB typical from 0.01GHz to 20GHz
- 0.7dB typical from 20GHz to 30GHz
- Power handling
- 37dBm continuous wave typical to 6GHz
- >44dBm pulsed typical to 2GHz
- Flat leakage
- 17dBm typical from 0.01GHz to 20GHz
- 15dBm typical from 20GHz to 30GHz
- Recovery time: <10ns
- Extended operating temperature range: −55°C to +125°C
- RoHS-compliant, 2mm × 2mm × 0.85mm, 8-lead LFCSP
产品详情和应用
The ADL8201 is a DC to 30GHz, high power, reflective RF limiter ensuring protection of sensitive circuitry.
Typical insertion loss, input return loss (RFIN), and flat leakage are 0.7dB, 18dB, and 15dBm, respectively, from 20GHz to 30GHz. The ADL8201 can withstand 37dBm continuous wave at 6GHz and >44dBm pulsed RF input to 2GHz. The recovery time is less than 10ns. The ADL8201 is internally matched to 50Ω and does not require any external circuitry.
The ADL8201 is fabricated on a gallium arsenide (GaAs) and housed in an RoHS-compliant, 2mm × 2mm × 0.85mm, 8-lead LFCSP. The ADL8201 is specified for operation over an extended temperature range of −55°C to +125°C.
APPLICATIONS
- RF transceivers
- Radar applications
- Test and measurement
