TI德州仪器 MAX20323A 产品介绍
2026-04-14
0次
说明
- Flexible System Design
- Wide Operating Supply Voltage Range: 2.5V to 5.5V
- Integrated 270mΩ (typ) Switch per Channel with 1A Continuous Current Capability
- Low Supply Current of 20µA (typ) when CC Inputs Are Under Overvoltage Threshold
- Accurate Pullup Currents to CC Outputs When CC Inputs Exceed Overvoltage Threshold (Except MAX20323A/C/F)
- Accurate OVLO Threshold: 5.75V±0.2V
- Surge Immunity:
- MAX20323/A/B: Over ±90V
- MAX20323C/D/E/F: ±80V with No VENCC or ±60V with Valid VENCC
- 12-Bump 0.4mm Pitch 1.7mm x 1.32mm WLP
特性
应用
- 工业PC
- 平板设备
- 智能电话
- 平板电脑
