说明
- Ultra-low RMS Noise: 1.3μVRMS (10Hz to 100kHz)
- Ultra-low Spot Noise: 3.5nV/√Hz at 10kHz
- Ultra-low 1/f Noise: 11μVP-P from 0.1Hz to 10Hz
- High PSRR at High-Frequency: 49dB at 1MHz
- Ultra-fast Transient Response
- Dropout Voltage: 55mV Typical
- Digitally Programmable VOUT: 0.5V to 4.2V
- High Accuracy: ±1.5% Over Line, Load, and Temperature
- Precise Current Monitor: ±3% accuracy at 5A
- Programmable Current Limit: ±3% at 5A
- Input Voltage Range: 0.6V to 5.5V
- Digital Output Margining: ±2.5%
- Stable with Ceramic Output Capacitors (22μF Minimum)
- Parallel Multiple Devices for Higher Current
- VIOC Pin to Control Upstream Switching Converter
- Precision Enable/Undervoltage Lockout (UVLO)
- Power Good (PG) Flag
- Internal Die Temperature Monitor
- 22-Lead (3mm x 4mm) LQFN Package
特性
The LT3078 is a low voltage, ultra-low noise, high power-supply rejection ratio (PSRR), and ultra-fast transient response linear regulator. The device supplies up to 5A with a typical dropout voltage of 55mV. A 4.7μF reference bypass capacitor decreases output voltage noise to 1.3μVRMS (10Hz to 100kHz). The wide bandwidth and high PSRR deliver the best performance without the need of bulky capacitors, which save space and cost. The LT3078 is ideal for powering high-performance FPGAs, data converters, RF, and all noise-sensitive signal chain applications.
The output voltage is digitally selectable in 50mV increments from 0.5V to 1.2V, 100mV increments from 1.2V to 1.8V, and discrete levels at 2V, 2.5V, 3V, 3.3V, and 4.2V. The LT3078’s unity-gain operation provides virtually constant output noise, PSRR, and bandwidth independent of the programmed output voltage. In addition, the LT3078 incorporates a unique tracking feature (VIOC) to control the upstream switching regulator to maintain a constant voltage across the LT3078 and minimize power dissipation.
A precision current monitor enables system energy management and allows the user to minimize input power-supply size and cost. Built-in protection includes UVLO, internal current limit, and thermal shutdown with hysteresis. The LT3078 is available in a compact 22-lead (3mm X 4mm) LQFN package (Laminate package with QFN footprint).
APPLICATIONS
- RF Power Supplies: PLLs, VCOs, Mixers, LNAs, PAs
- High Speed/High Precision Data Converters
- Low Noise Instrumentation
- Post-Regulator for Switching Supplies
- FPGA and DSP Power Supplies
- Medical Applications
